Cisco Unified IP Phone 7911 Series VOIP PoE LCD Business Phone CP-7911G

Cisco Unified IP Phone 7911 Series VOIP PoE LCD Business Phone CP-7911G

Condition Pre-owned

(Phones are removed from a working environment - tested, booting to the

screen saying "Registering"

No further testing was done, phones may have some scratches, actual pictures)

Specifications

The Cisco® Unified IP Phone 7911G fills the communication needs of

cubicle, retail, classroom, or

manufacturing workers or anyone who conducts low to moderate telephone

traffic. Four dynamic soft keys guide

users through core business features and functions, while a pixel-based

display combines intuitive features,

calling information, and eXtensible Markup Language (XML) services into

a rich user experience. The Cisco

Unified IP Phone 7911G offers numerous important security features plus

the choice of IEEE 802.3af Power

over Ethernet (PoE), Cisco inline power, or local power through an

optional power adaptor.

The Cisco Unified IP Phone 7911G is designed to grow with your

organization. A dynamic, soft-key driven

feature set enables the phone to keep pace with your requirements via

regular software upgrades. Moves, adds,

and changes are easy; users can simply pick up their phones and move to

a new location anywhere on the

network. The Cisco Unified IP Phone 7911G also provides accessibility

features to those with special needs.

Lighted Hold Key —Lights when pressed to put a call on hold and stays lit until the held call has been

resumed, or flashes if one call is held while another is engaged; is dark when no calls are on hold.

Lighted Menu Key —Lights when pressed to access voicemail messages, call logs, network settings, user

preferences, corporate directories, and XML services; stays lit while menu items are active.

Lighted Message Waiting Indicator —Lights when there is new voicemail and is visible on both the phone

chassis and the handset; stays lit until new voicemail has been processed by the user.

Graphical Display —Graphical monochrome display with resolution of 192 x 64 pixels provides a

scrollable 3-line intuitive access to calling features and text-based XML applications; the Cisco Unified IP

Phone 7911G also supports audio-based XML applications.

Four Soft Key Buttons and a Scroll Toggle —Dynamically present calling options to the user; the scroll

toggle bar allows easy movement through the displayed information.

Network Features —Cisco Discovery Protocol (CDP). IEEE 802.1 p/q tagging and switching.

Ethernet Switch —10/100BASE-T Ethernet connection through two RJ-45 ports, one for the LAN

connection, the other for connecting a downstream Ethernet device such as a PC.

Volume Control —A volume-control toggle provides easy decibel-level adjustments of the handset,

monitor speaker and ringer
